Push Button Switch
Micro Switch Push Button Switch Waterproof Micro Switch Rocker Switch Toggle Switch Slide Switch Indicator Light Other Switch
Detail
Specification:
Rating: 1.5A 250V AC
Contact Resistance:50mΩ Max
Insulation Resistance:DC500V 100mΩ MIN
Dielectric strength: AC 1000V for 1 minute
Operating Force: 250±50gf
Total Travel: 2.4±0.4mm
Operating Temperature：-10～80℃
Life Cycle: 10,000 Cycle
Function: OFF-(ON)
Application:
Lighting Fixtures
Automated production
Instruments and meters
Audio products
Testing equipment
Electrical toys
